Product Description
Our High Voltage High Frequency Transformer incorporates advanced magnetic core materials (such as ferrite, amorphous, and nanocrystalline) and innovative winding structure designs. It operates stably and efficiently within frequency ranges from kHz to several hundred kHz, with voltage capabilities spanning from several kilovolts to hundreds of kilovolts. This high voltage high frequency transformer offers extremely high power density and energy conversion efficiency. Compliant with international and domestic standards, it is an ideal choice for high-end applications like switch-mode power supplies, inverter systems, and pulsed power devices.
Product Parameters
|
Item |
Specification |
|
Product Line |
GT Series High Voltage High Frequency Transformer |
|
Operating Frequency |
1 kHz - 500 kHz (Customizable) |
|
Rated Voltage |
Up to 150 kV (Customizable) |
|
Insulation Class |
Class F, Class H, or Higher |
|
Core Material |
Ferrite, Amorphous, Nanocrystalline, etc. |
|
Cooling Method |
AN (Air Natural), AF (Air Forced), Oil Cooling |
|
Key Technologies |
Low Partial Discharge, Low Eddy Current Loss, Optimized Insulation Structure |
Product Advantages
High Power Density & Efficiency
The high-frequency design significantly reduces the transformer's size and weight, achieving remarkable power density. Utilizing low-loss core materials and specialized conductors (e.g., Litz wire) effectively minimizes core and winding AC losses, with conversion efficiency exceeding 95%.
Excellent Insulation & Voltage Resistance
Advanced processes such as multi-layer insulation, vacuum impregnation, and epoxy casting ensure superior electrical insulation strength and corona resistance under high-voltage conditions. The partial discharge level is far below industry standards, guaranteeing long-term operational safety.
Outstanding Thermal Stability & Reliability
Scientific thermal management design and high-quality materials enable the high voltage high frequency transformer to maintain excellent thermal stability even under high-power loads. Its robust structure, strong shock resistance, and suitability for harsh industrial environments ensure long service life with minimal maintenance.
Main Applications
Our high voltage high frequency transformer is a critical component in the following cutting-edge fields:
Medical Equipment
High-voltage power supplies for advanced medical imaging systems (e.g., CT scanners, X-ray machines) and laser therapy devices.
01
Industrial & Scientific Research
High-frequency induction heating power supplies, electrostatic precipitator power supplies, pulsed power devices, and scientific research accelerators.
02
Power Electronics
High-power switch-mode power supplies (SMPS), uninterruptible power supplies (UPS), and traction converters for rail transportation.
03
Defense & Aerospace
Radar systems, communication equipment, and airborne power supplies where weight, size, and reliability are critical.
04
Our Factory
Baoding Tianwei Baoqian Electric Power Equipment Co., Ltd. is a premier manufacturer of power equipment, founded in 2004 and headquartered in the Baoding High-Tech Zone. With a registered capital of 100 million RMB, we specialize in the research, development, and production of a diverse portfolio of power equipment, including high-performance dry-type and oil-immersed transformers.
Our state-of-the-art manufacturing facility is supported by advanced production lines and a stringent quality management system, certified to relevant ISO standards. Through collaboration with leading technical experts and renowned academic institutions, we continuously advance our product design and manufacturing capabilities. We are dedicated to delivering superior, reliable products and customized solutions to customers worldwide, reinforced by a comprehensive after-sales service network that guarantees complete customer satisfaction.
